Smart Integrated Pump Station for Municipal Rainwater & Sewage
Equipment Features
1. Fully independent production, excellent quality;
2.The footprint is small, small impact on the surrounding environment;
3.Remote monitoring, high degree of intelligence level;
4.Simple construction, short cycle can reduce the site installation cycle and construction cost;
5.Long service life:he service life is more than 50 years.
Equipment Parameters
|
Processing capacity(m³/d) |
480 |
720 |
1080 |
1680 |
2760 |
3480 |
3960 |
7920 |
18960 |
|
Flow rate(m³/h) |
20 |
30 |
45 |
70 |
115 |
145 |
165 |
330 |
790 |
|
Height(m) |
3 |
3 |
3 |
4 |
5 |
5 |
6 |
6 |
9 |
|
Weight(t) |
2.1 |
2.5 |
2.8 |
3.1 |
3.5 |
4.1 |
4.5 |
5.5 |
7.2 |
|
Diameter(m) |
1.2 |
1.5 |
1.8 |
2.0 |
2.5 |
2.8 |
3.0 |
4.2 |
6.5 |
|
Volume(m³) |
1.6956 |
2.649375 |
3.8151 |
6.28 |
9.8125 |
12.3088 |
14.13 |
27.6948 |
66.3325 |
|
Power(kW) |
3 |
4.4 |
6 |
11 |
15 |
22 |
30 |
44 |
150 |
|
Voltage(v) |
Adjustable |
||||||||
The above data is for reference only. The parameters and selection are subject to mutual confirmation and can be combined for use. Other non-standard tonnage can be customized.
Application Scenarios
It is used in many scenarios such as municipal and industrial underground drainage, domestic sewage collection and transportation, urban sewage lifting, railway and highway water supply and drainage, etc.
