MBR integrated sewage treatment plant

Short Description:

MBR integrated sewage treatment is developed for sensitive water source areas discharge standards, the equipment single unit treatment capacity of 20-150 tons, the equipment internal integration of MBR membrane process, can maintain a high concentration of microbial amount, so that the effluent is stable and better than the first A. The equipment can be equipped with our self-developed LD-icloud intelligent water platform, to achieve 24-hour real-time online monitoring of equipment, to facilitate user management equipment. It is convenient for users to manage the equipment.

Send email to us

Product Detail

Product Tags

Equipment Features

1. Modular Design: Highly integrated modular design, the anoxic tank, MBR membrane tank and control room can be designed and installed separately according to the actual situation, which is easy to transport.

2. New Technology: Integration of new ultra-filtration membrane technology and biological simulation technology, high volume load, good effect of denitrogenation and phosphorus removal, low amount of residual sludge, short treatment process, no precipitation, sand filtration link, high efficiency of membrane separation makes the treatment unit hydraulic residence time greatly shortened, strong adaptability to changes in water quality, and strong impact resistance of the system.

3. Intelligent Control: Intelligent monitoring technology can be used to achieve fully automatic operation, stable operation, intuitive and easy to operate.

4. Small Footprint: less infrastructure works, only need to build equipment foundation, take over the treatment can be regenerated and reused, saving labor, time and land.

5. Low Operating Costs: low direct operating costs, high-performance ultrafiltration membrane components, longer service life.

6. High Quality Water: Stable water quality, pollutant indicators better than the "urban sewage treatment plant discharge standards" (GB18918-2002) level A standard, and the main discharge indicators better than the "urban wastewater recycling urban miscellaneous water quality" (GB/T 18920-2002) standard

Equipment Parameters

Model	Processing capacity（m³/d）	Size *LB(m)**	Weight（t）	Shell thickness（mm）	Installed power（KW）
SMBR20	20	4.8x3.1	3	10-12	5.1
SMBR30	30	6.1x3.1	3.5	10-15	6.2
SMBR50	50	7.3x3.5	5.1	10-15	7.8
SMBR60	60	9.2x3.5	4.8	10-15	8.1
SMBR100	100	12.3x3.5	5.9	10-20	9.5
SMBR150	150	14.0x3.5	7.9	10-20	14.3
Inlet water quality	General domestic sewage
Effluent quality	National standard Class A, some indicators meet the surface four water

Note: The above data are for reference only, parameters and selection are subject to confirmation by both parties, combinations can be used, other non-standard tonnage can be customized.
